Linear actuators

Precise, reliable, and highly customisable

We offer a comprehensive range of compact linear actuators with integrated driver, encoder, and homing sensors. With all metal gear, leadscrew, nut and body, these linear actuators are designed for precise positioning and repeatabliity in a simple to integrate package.

We have expertise and proven designs for miniature linear actuators which we can configure or design for OEM applications. We design matching driver and controller solutions to application requirements, and offer simulated application validation and lifetime testing services.

Linear Actuators

27 products in this category

Browse by Category

With selected rows


LA12-V06-S010-G010	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	68.5	10	6	220	0.44	Precious metal brush	10	Anodized aluminium alloy	4.167	80	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	20.7	8	15.8	-10	50
LA12-V06-S010-G030	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	68.5	10	6	195	0.42	Precious metal brush	30	Anodized aluminium alloy	1.389	20	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	7.1	25	5.45	-10	50
LA12-V06-S010-G100	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	68.5	10	6	130	0.395	Precious metal brush	100	Anodized aluminium alloy	0.421	10	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	2.2	80	1.7	-10	50
LA12-V06-S030-G010	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	89.2	30	6	220	0.44	Precious metal brush	10	Anodized aluminium alloy	4.167	80	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	20.7	8	15.8	-10	50
LA12-V06-S030-G030	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	89.2	30	6	195	0.42	Precious metal brush	30	Anodized aluminium alloy	1.389	20	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	7.1	25	5.45	-10	50
LA12-V06-S030-G100	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	89.2	30	6	130	0.395	Precious metal brush	100	Anodized aluminium alloy	0.421	10	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	2.2	80	1.7	-10	50
LA12-V06-S050-G010	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	111.8	50	6	220	0.44	Precious metal brush	10	Anodized aluminium alloy	4.167	80	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	20.7	8	15.8	-10	50
LA12-V06-S050-G030	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	111.8	50	6	195	0.42	Precious metal brush	30	Anodized aluminium alloy	1.389	20	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	7.1	25	5.45	-10	50
LA12-V06-S050-G100	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	111.8	50	6	130	0.395	Precious metal brush	100	Anodized aluminium alloy	0.421	10	Fully retracted	Magnetic	Magnetic	0.2	80	1.1	3.2	0.6	2.2	80	1.7	-10	50
LA12-V09-S010-G010	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	68.5	10	9	155	0.3	Precious metal brush	10	Anodized aluminium alloy	4.167	80	Fully retracted	Magnetic	Magnetic	0.2	80	0.9	7.5	1.25	20.7	8	15.8	-10	50
LA12-V09-S010-G030	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	68.5	10	6	150	0.29	Precious metal brush	30	Anodized aluminium alloy	1.389	20	Fully retracted	Magnetic	Magnetic	0.2	80	0.9	7.5	1.25	7.1	25	5.45	-10	50
LA12-V09-S010-G100	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	68.5	10	9	102	0.27	Precious metal brush	100	Anodized aluminium alloy	0.421	10	Fully retracted	Magnetic	Magnetic	0.2	80	0.9	7.5	1.25	2.2	80	1.7	-10	50
LA12-V09-S030-G010	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	89.2	30	9	155	0.3	Precious metal brush	10	Anodized aluminium alloy	4.167	80	Fully retracted	Magnetic	Magnetic	0.2	80	0.9	7.5	1.25	20.7	8	15.8	-10	50
LA12-V09-S030-G030	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	89.2	30	9	150	0.29	Precious metal brush	30	Anodized aluminium alloy	1.389	20	Fully retracted	Magnetic	Magnetic	0.2	80	0.9	7.5	1.25	7.1	25	5.45	-10	50
LA12-V09-S030-G100	Linear Actuator Brushed (precious metal brushes)	8 weeks	Brushed	89.2	30	9	102	0.27	Precious metal brush	100	Anodized aluminium alloy	0.421	10	Fully retracted	Magnetic	Magnetic	0.2	80	0.9	7.5	1.25	2.2	80	1.7	-10	50

Showing 1-15 of 27

Page 1 of 2

We design and manufacture miniature linear actuators:

10-50mm travel, or customised to fit your application,
Full integrated drivers with sensors,
Winding voltages from 6v to 18v, windings available off-the-shelf for sampling,
OEM variants and custom designs with stepper, coreless or brushless configuration

We also design and manufacture quick turnaround mechanisms using brushless motors:

Slider tables,
Ball screw and belt drive positioners,
Levers, cams and other slider arrangements,
Complex mechanisms: Fully bespoke ground-up designs for complex applications,

Contact our application engineering team to discuss your project support@precisionmicrodrives.com, or use the contact form below.

Contact us

You need our support. We're here to help.

Motor products are difficult to understand, specify, validate and integrate into end application. The industry has no standards and suppliers typically offer only fragments of advice.

We know what you don't and can mitigate your motor design, manufacturing and supply risks.

Get in touch with our team today.
